Compax3 Accessories
I11 T11 192-120101 N6 - March 2004 107
(1
Length code 1
Length [m] 1.0 2.5 5.0 7.5 10.0 12.5 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
Code 01 02 03 04 05 06 07 08 09 10 11 12 13 14
SSK01/09: Length 25 m
(2
Colors according to DESINA
(3
With motor connector
(4
With cable eye for motor terminal box
(5
Length code 2 for SSK28
Length [m] 0.25 0.5 1.0 3.0 5.0 10.0
Code 20 21 01 22 03 05
(6
Order code: SSK27/nn/..
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connection from Pop to one Compax3
MOK55 and MOK54 can also be used for linear motors LXR406, LXR412 and
BLMA.
Example:
Examples:

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
