Compax3 device description
34 I11 T11 192-120101 N6 - March 2004
3.2.4. Installation and dimensions of Compax3 S300 V4
Mounting:
4 socket head screws M5
Mounting spacing:
Device separation 15 mm
3
8
0
4
0
0
4
1
2
3
9
1
175
80
6
Compax3 S300 V4 is force-ventilated via a fan integrated into the heat
dissipater!
