Status values
90 I11 T11 192-120101 N6 - March 2004
6.8 IEC61131-3
Status of cycle time of the control program
Object 50.3
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
standard
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Current cycle time [unit: 1=500 µs] of the control program
Status of maximum cycle time
Object 50.4
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
standard
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Maximum cycle time [unit : 1=500 µs]
Very large values may occur here with the command "Save objects
permanently". Then the control program will no longer be executed for
the execution time (about 1.5 sec)
Setpoint for analog output 0
Object 634.4
Available in technology function:
T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Setpoint for analog output 0 (DA0 - X11/4); can be used as a DA
monitor.
This output must be previously activated to be able to access it. You
can do this in the ServoManager in the optimization window in the
partial window at the bottom left under DA monitor.
Convert the signal source to IEC61131.
Setpoint for analog output 1
Object 635.4
Available in technology function:
T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Setpoint for analog output 1 (DA1 - X11/3); can be used as DA monitor.
This output must be previously activated to be able to access it. You
can do this in the ServoManager in the optimization window in the
partial window at the bottom left under DA monitor.
Convert the signal source to IEC61131.
