Status values
I11 T11 192-120101 N6 - March 2004 83
6.1 Device
Status of device utilization
Object 683.2
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
%
User level
standard
D/A monitor output
not possible
D/A monitor: measurement unit of
the reference value
-
Remark:
Device utilization
Stated in % of the nominal device current
Status of power output stage temperature
Object 684.1
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
C
User level
standard
D/A monitor output
not possible
D/A monitor: measurement unit of
the reference value
-
Remark:
Power output stage temperature
Status of auxiliary voltage
Object 685.1
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
V
User level
standard
D/A monitor output
not possible
D/A monitor: measurement unit of
the reference value
-
Remark:
Control voltage
Status DC bus voltage
Object 685.2
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
V
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
V
Remark:
unfiltered signal
6.2 Motor
Status of motor temperature
Object 684.2
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
C
User level
standard
D/A monitor output
not possible
D/A monitor: measurement unit of
the reference value
-
Remark:
Motor temperature
measured via the sensor in the motor, correct display only with KTY84
Status of short-term motor utilization
Object 683.4
Available in technology function:
T10, T11, T30, T40
