Setting up Compax3
I11 T11 192-120101 N6 - March 2004 75
4.4.2. Commissioning mode
The functions Manual+/- are made available via the setup mode. Setup mode can
be activated in the ServoManager under the menu item "Optimization". The
following applies in setup mode:
Function Input PIN
Manual+ I5 X12/12
Manual- I6 X12/13
Thus only 3 positioning data records, which can be accessed via the address lines
0 and 1, are available in setup mode.

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
