Page #85 background image
Parker EME
Status values
I11 T11 192-120101 N6 - March 2004 85
Available in technology function:
T11, T30, T40
Unit of
measurement
Unit
User level
advanced
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Revolutions
Remark:
Stated in user units, continuous position
Status actual position without absolute reference
Object 680.13
Available in technology function:
T11, T30, T40
Unit of
measurement
Unit
User level
advanced
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Revolutions
Remark:
Stated in user units, continuous position
6.4 Speeds
Status target speed of setpoint encoder
Object 681.4
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Unit/s
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Rev/s
Remark:
Target value according to the fine interpolator
Status target speed controller input
Object 681.10
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Unit/s
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Rev/s
Remark:
Nominal speed
Target speed value on the controller input including feed forward
Status actual speed filtered
Object 681.9
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Unit/s
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Rev/s
Remark:
Actual speed filtered
Status actual speed unfiltered
Object 681.5
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Unit/s
User level
advanced
D/A monitor output
possible
D/A monitor: measurement unit of
the reference value
Rev/s
Remark:
Status control deviation of speed
Object 681.6
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Unit/s
User level
standard
