Status values
I11 T11 192-120101 N6 - March 2004 91
6.9 Transmitter
Status of sine in signal processing
Object 692.1
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Sinus trace resolver, für F10 devices
The value 1 corresponds to 2.5 Volts
The amplitude must be <1 and > 0.1 at the resolver; otherwise a level
error is reported.
Status of cosine in signal processing
Object 692.2
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Cosine trace of resolver, for F10 devices
The value 1 corresponds to 2.5 Volts
The amplitude must be <1 and > 0.1 at the resolver; otherwise a level
error is reported.
Status of analog input sine
Object 692.3
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Sine trace of encoder, für F11 and F12 devices (0.5 = 2.5V)
Status of analog input cosine
Object 692.4
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Cosine trace of encoder, für F11 and F12 devices
Status of feedback level
Object 692.5
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
V
User level
advanced
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Feedback level, for F11 and F12 devices, display in Vpp
(=sqrt(sin²+cos²))
