Parker EME
Compax3 Accessories
I11 T11 192-120101 N6 - March 2004 121
8.4.4. Motor cable with plug
MOK55/.. (max. 13.8A)
Cable: 6x1.5 mm
2
PE ( )
0V
+24V
W
V
U
6
5
2
1
3
4
Br-
Br+
W
V
U
6
42
1
5
3 ( )
bk1
bk2
bk3
bk4
bk5
gn/ye
bk1
bk2
bk3
bk4
bk5
gn/ye
140 mm
75 mm
65 mm
10 mm
Lötseite / solder side
Crimpseite / crimp side
Schirm auf Schirmanbindungselement
Screen at screen contact
Bremse/
Brake
MOK54/..: (max. 13.8 A) cable chain compatible
Same structure as MOK55/.. available in cable chain compatible version.
MOK56/..: (max. 18.9A)
Same structure as MOK55, but with 6x2.5 mm
2
MOK57/..: (max. 18.9 A) cable chain compatible
Same structure as MOK55, but with 4x2.5 + 2x1 mm
2
and cable chain compatible.
You will find the length code in the Accessories order code (see on page 106)
