Parker Compax3 S150 V4 User Manual

Status values
82 I11 T11 192-120101 N6 - March 2004
In this chapter you can read about:
Device ............................................................................................................................................83
Motor..............................................................................................................................................83
Positions.........................................................................................................................................84
Speeds ...........................................................................................................................................85
Currents .........................................................................................................................................87
Inputs .............................................................................................................................................88
CAM...............................................................................................................................................89
IEC61131-3 ....................................................................................................................................90
Feedback system ...........................................................................................................................91
A list of the status values supports you in optimization and commissioning.
Open the optimization function in the C3 ServoManager (double-click on
optimization in the tree)
You will find the available status values in the lower right part of the window under
selection (TAB) “Status values“
You can pull them into the oscilloscope (upper part of the left side) or into the
status display (upper part of the right side) by the aid of the mouse (drag and drop).
The status values are divided into 2 groups (unser levels):
standard: here you can find all important status values
advanced: advanced status values, require a better knowledge
The user level can be changed in the optimization window (left hand side lower part
under selection (TAB) "optimization") with the following button.
A part of the status values can be output via the D/A monitor channel 0 (X11/4) and
channel 1 (X11/3).
The reference for the output voltage can be entered individually in the reference
unit of the D/A monitor.
Note
The unit of measurement of the D/A monitor values differs from the unit of
measurement of the status values.
6. Status values
Switching of the
user level
D/A-Monito
r
