Page #87 background imageLoading...
Page #87 background image
Parker EME
Status values
I11 T11 192-120101 N6 - March 2004 87
6.5 Currents
Status of effective target current (torque forming)
Object 688.1
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit
of the reference value
O
Remark:
Effective target current (torque forming)
Cross-flow target value including current and jerk feed forward
Status of effective actual current (torque forming)
Object 688.2
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit
of the reference value
O
Remark:
Effective actual current (torque forming), actual value after filter
Status of control deviation of effective current
Object 688.8
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
advanced
D/A monitor output
possible
D/A monitor: measurement unit
of the reference value
O
Remark:
Control deviation of effective current (torque forming)
Status of voltage control signal
Object 688.11
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
n/a
User level
advanced
D/A monitor output
not possible
D/A monitor: measurement unit
of the reference value
-
Remark:
Control signal of current controller (torque forming)
0.577 correspond to full range (Terminal voltage=DC bus voltage)
Status of current phase U
Object 688.9
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
advanced
D/A monitor output
not possible
D/A monitor: measurement unit
of the reference value
-
Remark:
Phase current U, Output as peak value
Actual value after oversampling
Status of current phase V
Object 688.10
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
advanced
