8.6 External ballast resistors
In this chapter you can read about:
Ballast resistor BRM8/01 ..............................................................................................................128
Ballast resistor BRM5/01 ..............................................................................................................128
Ballast resistor BRM6/02 ..............................................................................................................128
Ballast resistor BRM4/0x...............................................................................................................129
Danger!
Hazards when handling ballast resistors!
Housing temperature up to 200°C!
Dangerous voltage!
The device may be operated only in the mounted state!
The external ballast resistors must be installed such that contact with
the human body is prevented.
Install the connecting leads at the bottom.
Observe the instructions on the resistors (warning plate).
The ballast resistors are equipped with a 1.5m connecting lead.
Please note that the length must not exceed 2m
Ballast resistors for Compax3
Ballast resistor Device sustained dynamic
BRM8/01 (100Ω
ΩΩ
Ω)
Compax3 S025 V2
Compax3 S038 V4
60W
250W (<1s;
≥10s cooling time)
BRM5/01 (56Ω
ΩΩ
Ω)
Compax3 S063 V2
Compax3 S075 V4
180W
2300W (<0.4s;
≥8s cooling
time)
BRM6/02 (33Ω
ΩΩ
Ω)
Compax3 S150 V4 570W
6900 W (<1s;
≥ 20s cooling
time)
BRM4/01 (15Ω
ΩΩ
Ω)
Compax3 S300 V4 570W
6900 W (<1s;
≥ 20s cooling
time)
BRM4/02 (15Ω
ΩΩ
Ω)
Compax3 S300 V4 740W
8900W (<1s;
≥20s cooling time)
BRM4/03 (15Ω
ΩΩ
Ω)
Compax3 S300 V4 1500W
18kW (<1s;
≥20s cooling time)
