Compax3 Accessories
118 I11 T11 192-120101 N6 - March 2004
8.3.2.7 Order code for SMH/MH motors
SMH / MH motors
Motor type
MH: MH motor (resolver)
SMH: SMH motor (resolver)
A: with brake
1)
Cooling available on MH105/145/205)
V: passive cooling
2)
SV: active cooling
3)
Size of motor
SMH: 60/82/100
MH: 56/70/105/145/205
Speed
in 100’s of rpms at 400 VAC
4)
Type of motor (as specified in the tables)
Flange type B...
5, 6, 8, 9 or 4 for flange 14
5)
Shaft diameter
9/11/14/19/24/28/38/42
Shaft
S: without feather key
Type of connections
2ID: SMH60/82/100/MH56
2I: MH70/105
3I: MH145/205
Protection class
64: IP64
65: IP65 (standard)
SinCos© type
A6: Singleturn (SRS50)
6)
A7: Multiturn (SRM50)
6)
Increased moment of inertia
M (available on MH105/145/205)
ML (available on MH105/145/205)
7)
Mains power supply (drive)
4: 400VAC
4)
1)
MHA56 not available.
2)
Resulting in longer motor: MH105 +34mm; MH145 +44mm; MH205 +54mm.
3)
Resulting in longer motor: MH105 +64mm; MH145 +97mm; MH205 +109mm
Supply voltage: MH105: 24VDC; MH145: 230VAC; MH205: 230VAC.
4)
Except for motors which are designed for 230V, then the following applies: Speed = 230V speed; mains power supply “2” for 230VAC.
5)
For availability see the dimension tables.
6)
Not for MH56 and MH70. (SMHA 60 on inquiry)
7)
Not for MH105 08, MH145 28 and MH205 90.
Additional options on request (Encoder, Explosion protection).
