Compax3 Accessories
114 I11 T11 192-120101 N6 - March 2004
8.3.2.2 Holding brake
On request the motors can be equipped with a holding brake. The brake is
mounted in the motor housing on the B-side. The mechanical dimensions of the
motor are changed. See the dimensions table. The power supply infeed is through
the motor cable. Please see to the poling being correct.
Technical data of the 24V holding brakes:
SMHA motors
Motor type SMHA 60 SMHA 82 SMHA 100
Power supply voltage ±
±±
±10%
24 24 24 V
Current at 20°C
0.34 0.5 0.67 O
Resistance at 20°C
71 48 35.8
Ω
Max. static braking torque
2.2 5 11 Nm
Backlash
000
Moment of Inertia
13 43 104 kgmm
2
MHA motors
Motor type MHA 56 MHA 70 MHA 105 MHA 145 MHA 205
Power supply voltage ±
±±
±10%
24 24 24 24 24 V
Current at 20°C
0.32 0.53 1,1 1.8 1.65 O
Resistance at 20°C
76 45 22 13.2 14.5
Ω
Max. static braking torque
1.25 2.5 10 30 100 Nm
Backlash
00000
Moment of Inertia
17 29 62,5 195 1000 kgmm
2
Attention: The holding brake does not allow active braking.
8.3.2.3 Pulse encoder systems
A resolver is built into the motors in their standard configuration.
The motors are optionally available with the following encoders:
! SinCos Singleturn encoder or
! SinCos Multiturn absolute value encoder
