Compax3 Accessories
126 I11 T11 192-120101 N6 - March 2004
8.5.2.3 Motor output filter MDR01/02
up to 30 A rated motor current
Dimensional drawing:
180
76
110
6
136
57
1
9
5
U1 V1 W1 + - U2 V2 W2 + -
8.5.2.4 Wiring of the motor output filter
M
Motor
MDR
Compax3
PE
PE
U
V
W
Br+
Br-
++
-
-
U1
U2
V2V1
W1
W2
