Status values
I11 T11 192-120101 N6 - March 2004 89
Unit of
measurement
Revolutions
User level
standard
D/A monitor output
not possible
D/A monitor:
measurement unit of the
reference value
-
Remark:
Encoder input 0 (5V), counter state in turns of the encoder
Status of encoder input 0 (24V)
Object 680.11
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
Revolutions
User level
standard
D/A monitor output
not possible
D/A monitor: measurement
unit of the reference value
-
Remark:
Encoder input 1 (24V), counter state in turns of the encoder
6.7 CAM
Status of signal source of master position monitoring
Object 3021.2
Available in technology function:
- T40
Unit of
measurement
Revolutions
User level
standard
D/A monitor output
possible
D/A monitor: measurement
unit of the reference value
Revolutions
Remark:
Status of master position
Object 3030.1
Available in technology function:
- T40
Unit of
measurement
Munit
User level
standard
D/A monitor output
possible
D/A monitor: measurement
unit of the reference value
Units
Remark:
reset
Status of slave position
Object 3032.1
Available in technology function:
- T40
Unit of
measurement
Unit
User level
standard
D/A monitor output
possible
D/A monitor: measurement
unit of the reference value
Units
Remark:
reset position after cam table [Units]
