Parker EME
Compax3 Accessories
I11 T11 192-120101 N6 - March 2004 109
given as a percentage of the reference current). Note that values that are too high
will cause Error 0x73A6 to be triggered.
Typically the motor moves by 4% of the pitch length or, with rotary direct drives 4%
of 360°/number of pole pairs - maximum 50%.
Note the following conditions for automatic commutation
! The linear motor must not be at the end limits for automatic commutation.
! Actively working load torques are not permitted during automatic commutation.
! Rubbing caused by friction deteriorates the effect of automatic commutation.
! With the exception of missing commutation information, the controller/motor
combination is configured and ready for operation (parameters correctly assigned
for the linear motor/drive). The transmitter and the direction of the field of rotation
in effect must match.
! The auto-commutating function must be adapted to fit the mechanics if necessary
during commissioning.
8.3.1.2 Linear motors
Parker offers you a number of systems of linear motor drives:
Linear motors
Feed force
(continuous/dynamic)
Stroke length:
Linear motor kit SL:
475N / 739N As required
Linear motors of the LXR series:
315N / 1,000N Up to 3 m
Linear motor module BLMA:
605N / 1,720N Up to 6m
8.3.1.3 Torque motors
Parker offers you an extensive range of torque motors that can be adapted to your
application. Please contact us for information.
