Page #88 background imageLoading...
Page #88 background image
Status values
88 I11 T11 192-120101 N6 - March 2004
D/A monitor output
not possible
D/A monitor: measurement unit
of the reference value
-
Remark:
Phase current V, Output as peak value
Actual value after oversampling
Status of target jerk setpoint encoder
Object 688.13
Available in technology function:
T11, T30, T40
Unit of
measurement
Unit/s³
User level
advanced
D/A monitor output
not possible
D/A monitor: measurement unit
of the reference value
-
Remark:
Target jerk of setpoint encoder
Stated in user units
Output value of the fine interpolator
Status of effective current and jerk forward feed
Object 688.14
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
mA
User level
advanced
D/A monitor output
not possible
D/A monitor: measurement unit
of the reference value
-
Remark:
Forward feed of effective current and jerk
Stated in amperes RMS
after filter
6.6 Inputs
Status of analog input 0
Object 685.3
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
V
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit
of the reference value
10V
Remark:
Analog input 0
Analog input on plug X11/9 and X11/11
Indication of the voltage measured on the input in volts
Status of analog input 1
Object 685.4
Available in technology function:
T10, T11, T30, T40
Unit of
measurement
V
User level
standard
D/A monitor output
possible
D/A monitor: measurement unit
of the reference value
10V
Remark:
Analog input 1
Analog input on plug X11/10 and X11/2
Indication of the voltage measured on the input in volts
Status of encoder input 0 (5V)
Object 680.10
Available in technology function:
T10, T11, T30, T40
