Parker Compax3 S150 V4 User Manual

Compax3 Accessories
138 I11 T11 192-120101 N6 - March 2004
8.10.4. Ref X11
SSK21/..: cable for X11 with open ends
5
Screen
2
7
3
6
9
1
Compax3
4
8
10
11
12
13
14
15
GY
PK
GN
RD
BU
WH
BN
YE
BK
VT
GYPK
RDBU
WHGN
BNGN
WHYE
YEBN
WHGY
GYBN
GY
PK
GN
RD
BU
WH
BN
YE
BK
VT
GYPK
RDBU
WHGN
BNGN
WHYE
YEBN
WHGY
GYBN
Pin 1
15
14
13
12
11
6
9
8
7
10
5
4
3
2
1
Lötseite
solder side
2 mm 6 mm
23 mm
You will find the length code in the Accessories order code (see on page 106)

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
