Technical Data
I11 T11 192-120101 N6 - March 2004 141
Power [hp]
(at 400VAC)
2.5kVA 5kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 4kHz 4kHz
Power loss for In
80 W 120W 160W 350W
Efficiency
94% 95% 97% 97%
Resulting nominal and peak currents depending on the switching
frequency of the power output stage
Compax3 S0xx V2 at 230VAV
Power output
stage switching
frequency
S025 V2 S063 V2
I
nominal
2.5A
eff
6.3A
eff
8kHz
pre-set
I
peak
(<5s)
5.5A
eff
12.6A
eff
I
nominal
2.5A
eff
5.5A
eff
16kHz
I
peak
(<2,5s) 5.5A
eff
12.6A
eff
Compax3 S0xx V4 at 3*400VAC
Power output
stage switching
frequency
S038 V4 S075 V4 S150 V4 S300 V4
I
nominal
--
15A
eff
30A
eff
4kHz
I
peak
(<5s) - -
30A
eff
60A
eff
I
nominal
3.8A
eff
7.5A
eff
10.0A
eff
26A
eff
8kHz
I
peak
(<2,5s) 9.0A
eff
15.0A
eff
20.0A
eff
52A
eff
I
nominal
2.5A
eff
3.7A
eff
5.0A
eff
14A
eff
16kHz
I
peak
(<2,5s) 5.0A
eff
10.0A
eff
10.0A
eff
28A
eff
Compax3 S0xx V4 at 3*480VAC
Power output
stage switching
frequency
S038 V4 S075 V4 S150 V4 S300 V4
I
nominal
--
13.9A
eff
30A
eff
4kHz
pre-set
I
peak
(<5s) - -
30A
eff
60A
eff
I
nominal
3.8A
eff
6.5A
eff
8.0A
eff
21.5A
eff
8kHz
I
peak
(<2,5s)
7.5A
eff
15.0A
eff
16.0A
eff
43A
eff
I
nominal
2.0A
eff
2.7A
eff
3.5A
eff
10A
eff
16kHz
I
peak
(<2,5s) 4.0A
eff
8.0A
eff
7.0A
eff
20A
eff
The values marked with grey re the pre-set values (standard values)!
Accuracy at the motor
For option F10: Resolver
! Position resolution: 16 bits (= 0.005°)
! Absolute accuracy: ±0.167°
For option F11: SinCos
! Position resolution: 19 bits (= 0.0002°)
! Absolute accuracy: ±0.005°

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
