Parker Compax3 S150 V4 User Manual

Compax3 device description
30 I11 T11 192-120101 N6 - March 2004
Note on F12:
+5V (Pin 4) is measured and controlled directly at the end of the line via Sense –
and Sense +.
Maximum length of cable: 100m
Caution! Pin 4 and Pin 5 must under no circumstances be connected!
Resolver cable (see on page 119)
SinCos cable (see on page 120)

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
