Parker Compax3 S150 V4 User Manual

Parker EME
Configuration
Defining the reference system
I11 T11 192-120101 N6 - March 2004 43
A reset path of 300 mm can be entered directly with numerator = 300 mm and
denominator = 1.
Reset mode is not possible for linear motors.
Please do use the reset function only in normal mode!
It is not appropriate to use the reset function in continuous mode.
Reset travel distance
Counter
Unit: unit of measure Range: depends on the unit selected Standard value: depends
on the unit selected
Unit Division Standard value
Increments 10 ... 1 000 000 0
mm 1 ... 2000 0
Degrees 1 ... 720 0
Denominator
Unit: - Range: 1 ... 1 000 000 Standard value: 0
Integer value
Turn off reset mode
Reset mode is turned off for numerator = 0 and denominator = 0.
Note:
