Parker Compax3 Series

Setting up Compax3 C3I22T11
166 192-120114 N5 C3I22T11 June 2008
Functions:
 Select background color: Adapt background color to personal requirements.
 Select grid color: Adapt grid color to personal requirements.
 Memorize OSCI settings in file: The settings can be memorized in a file on any
drive. The file ending is *.OSC.
 The format correspnds to an INI file and is presented in the appendix.
 open OSCI settings from file. Loading a memorized set of settings. The file
ending is *.OSC.
 Memorizing OSCI settings in the project: Up to four sets of OSCI settings can
be memorized in the current C3 ServoManager project. .
 open OSCI settings from project. If settings were memorized in the project,
they can be read in again.
 Memorize OSCI measurement in file: Corresponds to memorizing the setting;
the measurement values of the measurement are stored in addition. Thus it is
possible to memorize and read measurements completely with settings. The file
ending is *.OSM.
 Exporting measurement values into a CSV file: e.g. for reading into Excel.
