Parker Compax3 Series

Introduction
C3I22T11
10 192-120114 N5 C3I22T11 June 2008
In this chapter you can read about:
Device assignment .............................................................................................................10
Type specification plate
......................................................................................................11
Packaging, transport, storage ............................................................................................12
Safety Instructions..............................................................................................................13
Warranty conditions............................................................................................................15
Conditions of utilization ......................................................................................................16
1.1 Device assignment
This manual applies to the following devices:
 Compax3S025V2 + supplement
 Compax3S063V2 + supplement
 Compax3S100V2 + supplement
 Compax3S150V2 + supplement
 Compax3S015V4 + supplement
 Compax3S038V4 + supplement
 Compax3S075V4 + supplement
 Compax3S150V4 + supplement
 Compax3S300V4 + supplement
 Compax3H050V4 + supplement
 Compax3H090V4 + supplement
 Compax3H125V4 + supplement
 Compax3H155V4 + supplement
 Compax3M050D6 + supplement
 Compax3M100D6 + supplement
 Compax3M150D6 + supplement
 Compax3M300D6 + supplement
 Compax3MP10D6
 Compax3MP20D6
With the supplement:
 F10 (Resolver)
 F11 (SinCos
©
)
 F12 (linear and rotary direct drives)
 I22 T11
1. Introduction
