Parker Compax3 Series User Manual

Order code C3I22T11
342 192-120114 N5 C3I22T11 June 2008
8.2 Order code for mains module: Compax3MP
Example: C3MP10D6USBM00
C3M P D6 USB M00
Device model: Compax3M
Power module P
Nominal power; supply voltage
10kW; 400VAC (3-phase) 10 D6
20kW; 400VAC (3-phase) 20 D6
Interface:
USB connection USB
Options:
no additional supplement M00
8.3 Accessories order code
Order Code connection set for Compax3S
/
for C3S0xxV2 ZBH 02/01
ZBH 0 2 / 0 1
for C3S0xxV4 / S150V4 / S1xxV2 ZBH 02/02
ZBH 0 2 / 0 2
for C3S300V4 ZBH 02/03
ZBH 0 2 / 0 3
Order Code connection set for Compax3MP/Compax3M
/
for C3M050D6, C3M100D6, C3M150D6 ZBH 04/01
ZBH 0 4 / 0 1
for C3M300D6 ZBH 04/02
ZBH 0 4 / 0 2
for C3MP10 ZBH 04/03
ZBH 0 4 / 0 3
C3MP20 ZBH 04/03
ZBH 0 4 / 0 4
Order code for feedback cables
/
for Resolver
(2
for MH / SMH motors
REK 4 2 / ... ...
(1
for Resolver
(2
for MH / SMH motors (cable chain compatible)
REK 4 1 / ... ...
(1
for SinCos© – Feedback devi-
ces
(2
for MH / SMH motors (cable chain compatible)
GBK 2 4
/
.. ...
(1
for EnDat 2.1
(2
for MH / SMH motors (cable chain compatible)
GBK 3 8 / .. ...
(1
Encoder – Compax3
GBK 2 3 / ... ...
(1
for LXR linear motors (cable chain compatible)
GBK 3 3 / ... ...
(1
for BLMA linear motors (cable chain compatible)
GBK 3 2 / ... ...
(1
(x
Note on the cable (see page 345)

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
