Parker Compax3 Series User Manual

Introduction
C3I22T11
16 192-120114 N5 C3I22T11 June 2008
1.6 Conditions of utilization
In this chapter you can read about:
Conditions of utilization for CE-conform operation .............................................................16
Conditions of utilization for UL cert
ification Compax3S......................................................19
Conditions of utilization for UL cert
ification Compax3M .....................................................21
Current on the mains PE (leakage current)........................................................................22
Supply networks .................................................................................................................23
1.6.1. Conditions of utilization for CE-conform operation
- Industry and trade -
The EC guidelines for electromagnetic compatibility 2006/95/EC and for electrical
operating devices for utilization within certain voltage limits 2004/108/EC are fulfil-
led when the following boundary conditions are observed:
Operation of the devices only in the condition in which they were delivered,
i.e. with all housing panels.
In order to ensure contact protection, all mating plugs must be present on the devi-
ce connections even if they are not wired.
A mains filter is required in the mains input line if the motor cable exceeds a certain
length. Filtering can be provided centrally at the plant mains input or separately at
the mains input to each device or with C3M for each axis combination.
Devices in a commercial and residential area (limit values of Class C2 in ac-
cordance with EN 61800-3)
The following mains filters are available for independent utilization:
Device: Compax3 Order No.: Condition:
S0xxV2 NFI01/01 Only for motor lines > 10m
S1xxV2,
S0xxV4, S150V4
NFI01/02 Only for motor lines > 10m
S300V4 NFI01/03 independent of the length of the
motor cable (always required)
Device: Compax3 Order No.: Condition:
H050V4 NFI02/01 Only for motor lines > 10m
H090V4 NFI02/02 Only for motor lines > 10m
H1xxV4 NFI02/03 Only for motor lines > 10m
Industrial area (limit values class C3 in accordance with EN 61800-3)
Longer motor cable lengths are possible in industrial areas.
Devices in the industrial area (limit values class C3 in accordance with EN
61800-3)
The following mains filters are available for independent utilization:
Device: Compax3 Order No.: Condition:
MP10 NFI03/01 Reference axis combination 6x10m
MP10 NFI03/02 Reference axis combination 6x50m
MP20 NFI03/03 Reference axis combination 6x50m
Mains filter:

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
