Parker Compax3 Series User Manual

Compax3 device description C3I22T11
64 192-120114 N5 C3I22T11 June 2008
3.7.3.2 Function of the Bus LEDs
LED (red)
No. Signal Status Description
1 off
No Error The bus is operating
2 Single flash
Warning at least one of the error counters of the CAN
controller has reached the warning level.
3 Double flash
Error Communication Fault
4 Triple flash
Error Double Mac ID
5 on
Error Bus Off
If several errors occur at once, the error with the most significant number is repor-
ted.
LED green
Signal Status Description
Single flash
On-line
Not Connec-
ted
Online, not at the master (not allocated)
blinks (permanently)
On-line
Connected
Online, at the master (allocated)
on
On-line
I/O Connected
I/O Messages allocated
Single flash
1s200ms
On
Off
Double flash
1s200ms 200ms
On
Off
Triple flash
1s200ms 200ms
On
Off

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
