Parker Compax3 Series User Manual

Parker EME
Setting up Compax3
192-120114 N5 C3I22T11 June 2008 159
4.3 Optimization
In this chapter you can read about:
Optimization window.........................................................................................................160
Scope ...............................................................................................................................161
Controller optimization......................................................................................................169
Signal filtering with external command value ...................................................................237
Input simulation ................................................................................................................240
Setup mode ......................................................................................................................242
Load identification.............................................................................................................244
Alignment of the analog inputs .........................................................................................246
C3 ServoSignalAnalyzer...................................................................................................248
ProfileViewer for the optimization of the motion profile ....................................................285
Turning the motor holding brake o
n and off .....................................................................287
 Select the entry "Optimization" in the tree.
 Open the optimization window by clicking on the "Optimization Tool" button.

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
