Compax3 device description C3I22T11

58 192-120114 N5 C3I22T11 June 2008

3.6.7.1 Connect braking resistor C3H

Connecting the braking resistor:

PIN Designation

DBR+ + Braking resistor

DBR- - Braking resistor

Braking operation of Compax3HxxxV4

Controller type H050V4 H090V4 H125V4 H155V4

Capacitance / storable

energy

2600μF /

602Ws

3150μF /

729Ws

5000μF /

1158Ws

5000μF /

1158Ws

Minimum braking- resistan-

24Ω 15Ω 8Ω 8Ω

Maximum continuous cur-

rent

30A 45A 83A 83A

Mimimum line cross section: 2.5mm

Maximum line length: 2m

Maximum output voltage: 830VDC

3.6.7.2 Power supply voltage DC C3H

DC high voltage supply

PIN Description

DC+ + DC high voltage supply

DC- - DC high voltage supply

Warning!

Do not connect any braking resistor on DC+/DC- .
