Parker Compax3 Series User Manual

Parker EME
Compax3 device description
192-120114 N5 C3I22T11 June 2008 99
3.11.4.1 STO test protocol specimen
General information:
Project/machine:
Servo axis:
Name of the tester:
STO function test:
Test specifiction accor-
ding to the Compax3
release:
STO function test steps 1-
6:
o successfully tested
Acknowledgement safety
switching device:
o successfully tested
o is not used
Safe stop 1: o successfully tested
o is not used
Initial acceptance on: Repeat check on:
Signature of the tester Signature of the tester

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
