Parker Compax3 Series User Manual

Parker EME
Compax3 Accessories
192-120114 N5 C3I22T11 June 2008 373
9.4.1.16 Permissible braking pulse power: BRM13/01 with C3MP10D6
On request
9.4.1.17 Permissible braking pulse power: BRM14/01 with C3MP10D6
On request
9.4.2. Dimensions of the braking resistors
In this chapter you can read about:
BRM8/01braking resistors ................................................................................................373
BRM5/01 braking resistor.................................................................................................373
Braking resistor BRM5/02, BRM9
/01 & BRM10/01 ..........................................................374
Braking resistor BRM4/0x.................................................................................................374
Braking resistor BRM11/01 & BRM12/01
.........................................................................375
Braking resistor BRM13/01 & BRM14/01
.........................................................................375
9.4.2.1 BRM8/01braking resistors
Dimensional drawing:
6
7,5
4
0
20
240
225
9.4.2.2 BRM5/01 braking resistor
Dimensional drawing:
222
245
1
0
1
6
,
5
4
8
73
12

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
