Parker Compax3 Series User Manual

Setting up Compax3 C3I22T11
248 192-120114 N5 C3I22T11 June 2008
4.3.9. C3 ServoSignalAnalyzer
In this chapter you can read about:
ServoSignalAnalyzer – function range .............................................................................248
Signal analysis overview ..................................................................................................249
Installation enable of the ServoSignalAnalyzer ................................................................250
Analyses in the time range ...............................................................................................252
Measurement of frequenc
y spectra..................................................................................255
Measurement of frequenc
y responses .............................................................................258
Overview of the user interface..........................................................................................265
Basics of frequency response me
asurement ...................................................................279
Examples are available as a movie in the help file...........................................................284
4.3.9.1 ServoSignalAnalyzer – function range
The function range of the ServoSignalAnalyzer is divided into 2 units:
Analysis in the time range
This partof the function is freely available within the Compax3 ServoManager.
The Compax3 ServoManager is part of the Compax3 servo drive delivery range.
Analysis in the frequency range
This part of the function requires a licence key which you can buy (see page 250)
.
The lice
nce is a company licence and must only be bought once per company.
For each PC you need however an individual key, which you can request indivi-
dually.

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
