Parker Compax3 Series User Manual

Compax3 device description C3I22T11
46 192-120114 N5 C3I22T11 June 2008
Mains connection Compax3MP10D6
Device type Compax3MP10 230V 400V 480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
22Aeff 22Aeff 18Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
6kW 10 kW 10 kW
Maximum fuse rating per
device (=short circuit rating)
MCB miniature circuit breaker according to DIVQ.GuideInfo
Recommendation: (ABB) S203 UP-25K (480VAC)
Mains connection Compax3MP20D6
Device type Compax3MP20 230V 400V 480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
44Arms 44Arms 35Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
12kW 20kW 20kW
Maximum fuse rating per
device (=short circuit rating)
MCB miniature circuit breaker 50A according to
DIVQ.GuideInfo
Recommendation: (ABB) S203-U50K (440VAC)
Fuses 80A / 660VAC per supply leg according to UL-Guide
JFHR2
Recommendation: Bussmann 170M
The Compax3MPxxD6 devices must only be operated with three phases!
Always switch devices off before wiring them!
Dangerous voltages are still present until 5 minutes after switching
off the power supply!
Caution!

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
