Parker Compax3 User Manual

Technical Characteristics
C3I12T11
386
192-120113 N08 C3I12T11 - December 2010
UL certification for Compax3S
conform to UL:

according to UL508C
Certified

E-File_No.: E235342
The UL certification is documented by a "UL" logo on the
device (type specification plate).
“UL” logo:
UL-approval for PSUP/Compax3M
conform to UL:
 according to UL508C
Certified

E-File_No.: E235342
The UL certification is documented
by a “UL” logo on the device (type
specification plate).
Insulation requirements
Enclosure rating
Protection class in accordance with EN 60664-1
Protection against human contact
with dangerous voltages
In accordance with EN 61800-5-1
Overvoltage category
Voltage category III in accordance with
EN 60664-1
Degree of contamination
Degree of contamination 2 in accordance with
EN 60664-1 and EN 61800-5-1
Environmental conditions Compax3S and Compax3H
General ambient conditions
In accordance with EN 60 721-3-1 to 3-3
Climate (temperature/humidity/barometric
pressure): Class 3K3
Permissible ambient temperature:
Operation
storage
transport
0 to +45 °C class 3K3
–25 to +70 °C class 2K3
–25 to +70 °C class 2K3
Tolerated humidity:
no condensation
Operation
storage
transport
<= 85% class 3K3
<= 95% class 2K3
<= 95% class 2K3
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load ratings
<=2000m above sea level for 1% / 100m power
reduction
please inquire for greater elevations
Mechanic resonances:
EN 60068-2-6 (sinusoidal excitation)
Sealing
Protection type IP20 in accordance with
EN 60 529

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
