4.4.5.2 Operating Principle
Window Compax3 InputSimulator:
1. Row:Standard Inputs E7 ... E0 = “0” button not pressed; = “1” switch pressed
2. Row: Optional digital inputs (M10 / M12)
Green field: port 4 is defined as input
Red field: port 4 is defined as output
the least significant input is always on the right side
3. Row: If the button “deactivating physical inputs” is pressed, all physical, digital
inputs are deactivated; only the input simulation is active.
If both sources (physical and simulated inputs) are active, they are or-linked!
Caution!
Please consider the effects of the or-linking; above all on low-active
functions.
4. Row:Simulation of the analog inputs 0 and 1 in steps of 100mV.
The set value is added to the value on the physical input.
After the input simulation has been called up, all simulated inputs are on “0”.
When the input simulation is left, the physical inputs become valid.

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
