Parker EME
Status values
192-120113 N08 C3I12T11 - December 2010
321
In this chapter you can read about:
D/A-Monitor ................................................................................................................... 321
Status values ................................................................................................................. 321
A list of the status values supports you in optimization and commissioning.
Open the optimization function in the C3 ServoManager (double-click on
optimization in the tree)
You will find the available status values in the lower right part of the window under
selection (TAB) “Status values”.
You can pull them into the oscilloscope (upper part of the left side) or into the
status display (upper part of the right side) by the aid of the mouse (drag and drop).
The status values are divided into 2 groups (user levels):
standard: here you can find all important status values
advanced:Advanced status values, require a better knowledge
The user level can be changed in the optimization window (left hand side lower part
under selection (TAB) "optimization") with the following button.
7.1 D/A-Monitor
A part of the status values can be output via the D/A monitor channel 0 (X11/4) and
channel 1 (X11/3).In the following status list under D/A monitor output: possible /
not possible).
The reference for the output voltage can be entered individually in the reference
unit of the status value.
Example: Output Object 2210.2: (actual speed unfiltered)
In order to get an output voltage of 10V at 3000prm , please enter rev/s
(=3000rpm) as "value of the signal at 10V".
Hint
The unit of measurement of the D/A monitor values differs from the unit of
measurement of the status values.
7.2 Status values
Additional information on the topic of "status values" can be found in the online
help of the device.
7. Status values
Switching of the
user level
