Compax3 device description
192-120113 N08 C3I12T11 - December 2010
87
Access to the hazardous area
Actuate emergency power-off switch
Due to the interruption on two channels at the emergency power-off switch, the
safety switching device is deactivated - output Q3 is immediately “0”.
Channel 1: Via the Energize input, the Compax3 devices receive the command to
guide the drive to a currentless state (using the ramp configured in the C3
ServoManager for "drive disable").
Channel 1 feedback 1: The "Controller Feedback" Compax3 outputs supply
current to Relays K1 and K2.
Channel 2: After the delay time set in the safety switching device, (this time must
be set so that all drives are stopped after it has elapsed) the output Q4 = “0”, which
in turn deactivates the Enable inputs ENAin of the Compax3 devices.
Channel 2 feedback: Via the series circuit of all feedback contacts, the “Safe
Torque-off” status (all Compax3 devices without current) is reported.
Only if the drives are all at a standstill, the safety door may be opened and the
hazardous area may be accessed.
If the safety door is opened during operation and the emergency-power-off switch
was not triggered before, the Compax3 drives will also trigger the stop ramp.
Caution! The drives may still move.
If danger to life and limb of a person entering cannot be excluded,
the machine must be protected by additional measures (e.g. a safety
door locking).
3.10.2.5 Technical Characteristics STO Compax3S
Safety technology Compax3S
Safe torque-off in accordance with EN
ISO 13849: 2008, Category 3, PL d/e
Certified.
Test mark IFA 1003004

For implementation of the “protection
against unexpected start-up” function
described in EN1037.
 Please note the circuitry examples (see
on page 77).
Compax3S STO (=safe torque off)
Nominal voltage of the
inputs
24 V
Required isolation of the
24V control voltage
Grounded protective extra low voltage, PELV
Protection of the STO
control voltage
1 A
Grouping of safety level
STO switch-off via internal safety relay & digital
input: PL e, PFHd=2.98E-8
STO switch-off via internal safety relay & fieldbus:
PL d, PFHd=1.51E-7
A MTTFd=15 of the external PLC and STO cycles/year
< 500 000 are assumed.

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
