Setting up Compax3
192-120113 N08 C3I12T11 - December 2010
97
In this chapter you can read about:
Configuration ................................................................................................................... 97
Configuring the signal Source ........................................................................................ 153
Load control ................................................................................................................... 158
Optimization................................................................................................................... 163
4.1 Configuration
In this chapter you can read about:
Test commissioning of a Compax3 axis ........................................................................... 99
Selection of the supply voltage used ................................................................................ 99
Motor selection ................................................................................................................ 99
Optimize motor reference point and switching frequency of the motor current................ 100
Ballast resistor ............................................................................................................... 103
General drive ................................................................................................................. 103
Defining the reference system ....................................................................................... 104
Defining jerk / ramps ...................................................................................................... 128
Limit and monitoring settings ......................................................................................... 131
Operating mode / I/O assignment .................................................................................. 134
Encoder simulation ........................................................................................................ 139
Absolute- /continuous mode .......................................................................................... 139
Position mode in reset operation .................................................................................... 140
Defining the STOP function ........................................................................................... 140
Reg-related positioning / defining ignore zone ............................................................... 142
Write into set table ......................................................................................................... 143
Error response ............................................................................................................... 151
Configuration name / comments .................................................................................... 152
The general proceeding in order to operate an empty-running motor is described
here (see on page 99).
Configurations sequence:
The Compax3 ServoManager can be installed directly from the Compax3
DVD. Click on the corresponding hyperlink resp. start the installation
program "C3Mgr_Setup_V.....exe" and follow the instructions.
4. Setting up Compax3
Installation of the C3
ServoManager
