Parker Compax3 User Manual

Compax3 Accessories
C3I12T11
340
192-120113 N08 C3I12T11 - December 2010
10.3.1. Resolver cable
REK42/..
12
11
12
11
5
2
1
10
7
Ref+
Ref-
9
8
+Temp
-Temp
COS-
COS+
SIN-
SIN+
2x0,25
2x0,25
2x0,25
2x0,25
Pin 1
4
REFres+
REFres-
10
+5V
Tmot
COS-
COS+
SIN-
SIN+
4
NC
NC
NC
5
3
NC
6
7
8
15
13
14
9
NC
NC
NC
NC
NC
2
3
6
NC
1
NC
Resolver
GY
PK
GN
RD
BU
WH
BN
YE
GY
PK
GN
RD
BU
WH
BN
YE
Compax3 (X13)
27mm
Lötseite / solder side
Crimpseite / crimp side
Codiernut S = 20°
9
8
7
6
5
4
3
2
1
12
11
10
15
14
13
12
11
6
9
8
7
10
5
4
3
2
1
Lötseite
solder side
2 mm 6 mm
23 mm
Schirm auf Schirmanbindungselement
Screen at screen contact
The same cable (with changed conductor coloring) is available under the
designation REK41/.. in a version which is suitable for cable chain systems.
You can find the length code in the Chapter Order Code Accessories (see on
page 324).

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
