Control via RS232 / RS485 / USB
C3I12T11
192-120113 N08 C3I12T11 - December 2010
5.4.3. Definition of the states of the programmable status bits
(PSBs):
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
factory use
Enable2
PSB2
Enable1
PSB1
Enable0
PSB0
factory use
PSB2 PSB1
PSB0
="1": Set PSB
="0": leave PSB unchanged
The Bits 0 ... 2 monitor the states of the status bits at the end of a motion set, if the
bits were enabled via the respective Enable.
If Enable is set to "0", the respective PSB remains unchanged at the end of the
motion set.
PSB0: X22/12 or SW.13
PSB1: X22/13 or SW.14
PSB2: X22/14 or SW.15
5.5 Compax3 communication variants
In this chapter you can read about:
PC <-> Compax3 (RS232) ............................................................................................. 299
PC <-> Compax3 (RS485) ............................................................................................. 301
PC <-> C3M device combination (USB) ......................................................................... 302
USB-RS485 Moxa Uport 1130 adapter .......................................................................... 303
ETHERNET-RS485 NetCOM 113 adapter ..................................................................... 304
Modem MB-Connectline MDH 500 / MDH 504 ............................................................... 305
C3 settings for RS485 two wire operation ...................................................................... 306
C3 settings for RS485 four wire operation...................................................................... 307
Overview of all possible communication modes between Compax3 devices and a
PC.
