4.4.9. C3 ServoSignalAnalyzer
In this chapter you can read about:
ServoSignalAnalyzer - function range ............................................................................249
Signal analysis overview ................................................................................................250
Installation enable of the ServoSignalAnalyzer ...............................................................251
Analyses in the time range .............................................................................................253
Measurement of frequency spectra ................................................................................256
Measurement of frequency responses ...........................................................................259
Overview of the user interface ........................................................................................266
Basics of frequency response measurement ..................................................................279
Examples are available as a movie in the help file .........................................................284
4.4.9.1 ServoSignalAnalyzer - function range
The function range of the ServoSignalAnalyzer is divided into 2 units:
Analysis in the time range
This part of the function is freely available within the Compax3 ServoManager.
The Compax3 ServoManager is part of the Compax3 servo drive delivery range.
Analysis in the frequency range
This part of the function requires a license key which you can buy (see on page
251).
The license is a company license and must only be bought once per company.
For each PC you need however an individual key, which you can request
individually.
