Parker Compax3 User Manual

Compax3 Accessories
C3I12T11
328
192-120113 N08 C3I12T11 - December 2010
In this chapter you can read about:
Parker servo motors ...................................................................................................... 328
EMC measures .............................................................................................................. 331
Connections to the motor ............................................................................................... 339
External braking resistors .............................................................................................. 345
Condenser module C4 ................................................................................................... 359
Operator control module BDM ....................................................................................... 360
EAM06: Terminal block for inputs and outputs ............................................................... 361
Interface cable ............................................................................................................... 363
Options M1x .................................................................................................................. 368
10.1 Parker servo motors
In this chapter you can read about:
Direct drives .................................................................................................................. 328
Rotary servo motors ...................................................................................................... 330
10.1.1. Direct drives
In this chapter you can read about:
Transmitter systems for direct drives ..............................................................................329
Linear motors .................................................................................................................330
Torque motors ...............................................................................................................330
10. Compax3 Accessories

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
