Parker Compax3 User Manual

Parker EME
Order code
192-120113 N08 C3I12T11 - December 2010
327
(1
Length code 1
Length [m] 1.0 2.5 5.0 7.5 10.0 12.5 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0
Order code 01 02 03 04 05 06 07 08 09 10 11 12 13 14
Example:
SSK01/09: Length 25m
(2
Colors according to DESINA
(3
with motor connector
(4
with cable eye for motor terminal box
5
length code 2 for SSK28
Length [m] 0.17 0.25 0.5 1.0 3.0 5.0 10.0
Order code 23 20 21 01 22 03 05
(6
Order code: SSK27/nn/..
Length A (Pop - 1. Compax3) variable (the last two numbers according to the
length code for cable, for example SSK27/nn/01)
Length B (1. Compax3 - 2. Compax3 - ... - n. Compax3) fixed 50 cm (only if there is
more than 1 Compax3, i.e. nn greater than 01)
Number n (the last two digits)
Examples include:
SSK27/05/.. for connecting from Pop to 5 Compax3.
SSK27/01/.. for connecting from Pop to one Compax3
MOK55 and MOK54 can also be used for linear motors LXR406, LXR412 and
BLMA.
(x
Note on cable (see on page 327)

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
