Page #389 background imageLoading...
Page #389 background image
Parker EME
Technical Characteristics
192-120113 N08 C3I12T11 - December 2010
387
Cooling Compax3S and Compax3H
Cooling mode:
C3S025V2 ... S150V4: Convection
C3S300V4 & C3H: Forced air ventilation with
fan in the heat dissipator
Air flow rate:
459m
³
/h (C3H)
Supply:
C3S300V4, C3H050, C3H090 internal
C3H125, C3H155 external
220/240VAC: 140W, 2.5µF, Stator - 62
Optionally on request:
110/120VAC: 130W, 10µF, Stator - 16
Circuit breaker:3A
EMC limit values Compax3S and Compax3H
EMC interference emission
Limit values in accordance with EN 61 800-3,
Limit value class C3/C4 without additional
mains filter:
Information on C2 limit value classes (see on
page 19)
EMC disturbance immunity
Industrial area limit values in accordance with
EN 61 800-3
Ambient conditions PSUP/Compax3M
General ambient conditions
In accordance with EN 60 721-3-1 to 3-3
Climate (temperature/humidity/barometric
pressure): Class 3K3
Permissible ambient temperature:
Operation
storage
transport
0 to +40 °C Class 3K3
-25 to +70 °C
-25 to +70 °C
Tolerated humidity:
no condensation
Operation
storage
transport
<= 85% class 3K3
<= 95%
<= 95%
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load ratings
<=2000m above sea level for 1% / 100m power
reduction
please inquire for greater elevations
Sealing
Protection type IP20 in accordance with
EN 60 529
Mechanic resonances:
Class 2M3, 20m/s
2
;8-200Hz
Cooling PSUP/Compax3M
Cooling mode:
Forced air ventilation with fan in the heat
dissipator
EMV limit values PSUP/Compax3M
EMC interference emission
Limit values in accordance with EN 61 800-3,
Limit value class C3 with mains filter.
EMC disturbance immunity
Industrial area limit values in accordance with
EN 61 800-3
