13
Workshop Manual, TPD 1377E, issue 4 113
100 Series
Flywheel housing (if fitted)
To remove and to fit Operation 13-3
Special requirements
Note: Only 104-22 engines have the backplate and housing fitted together.
Torque Nm (lbf ft) kgf m
102-05, 103-07 15 (11) 1,5
103-10 50 (37) 5,1
103-13, 103-15, 104-19, 104-22 25 (18) 2,6
This document has been printed from SPI². Not for Resale
