Perkins 103-13 - Busbar; Glowplugs

3
34 Workshop Manual, TPD 1377E, issue 4
100 Series
Busbar / glowplugs
To remove and to fit Operation 3-10
Special requirements
Note: The diagram below shows a typical arrangement only.
Torque Nm (lbf ft) kgf m
Glowplugs 17 (12) 1,7
Contacts 17 (12) 1,7
