58 Workshop Manual, TPD 1377E, issue 4
100 Series
Flywheel, backplate and oil seal
To remove and to fit Operation 5-2
Special requirements
Notes:
To remove and fit the flywheel, see Operation 13-1.
On assembly, apply Powerpart silicone RTV sealing and jointing compound to the block (around screw
holes) before the backplate is fitted.
103-10, 103-13 and 103-15 engines only: Remember the position of the dowel (A1).
POWERPART products
Description Part number
Silicone RTV sealing and jointing compound 1861108
Flywheel setscrews : Torque Nm (lbf ft) kgf m Backplate setscrews : Torque Nm (lbf ft) kgf m
102-05, 103-07 73 (54) 7,4 102-05, 103-07 15 (11) 1,5
103-10 73 (54) 7,4 103-10 50 (37) 5,1
103-13, 103-15, 104-19, 104-22 73 (54) 7,4 103-13, 103-15, 104-19, 104-22 15 (11) 1,5
1
POWERPART silicone
gasket sealant
