Workshop Manual, TPD 1377E, issue 4 13
2
100 Series
Specifications 2
Basic engine data
Engine model 102-05 103-07 103-10 103-13 103-15 104-19 104-22
Engine build code KN KL KD KH KE KF KR
Number of cylinders 2333344
Cylinder
arrangement and
cycle
Vertical in line, four stroke cycle
Direction of rotation Clockwise, viewed from front
Induction system Naturally aspirated
Combustion system IDI special swirl
Nominal bore
67 mm
(2.6 in)
67 mm
(2.6 in)
75 mm
(2.9 in)
84 mm
(3.3 in)
84 mm
(3.3 in)
84 mm
(3.3 in)
84 mm
(3.3 in)
Stroke
64 mm
(2.5 in)
64 mm
(2.5 in)
72 mm
(2.8 in)
80 mm
(3.1 in)
90 mm
(3.5 in)
90 mm
(3.5 in)
100 mm
(3.9 in)
Compression ratio 24:1 24:1 23:1 22:1 22.5:1 22:1 22:1
Cubic capacity
0,451 ltrs.
(27.5 in³)
0,676 ltrs.
(41.2 in³)
0,954 ltrs.
(58.2 in³)
1,330 ltrs.
(81.1 in³)
1,496 ltrs.
(91.2 in³)
1,995 ltrs.
(121.7 in³)
2,216 ltrs.
(135.2 in³)
Firing order 1, 2 1, 2, 3 1, 2, 3 1, 2, 3 1, 2, 3 1, 3, 4, 2 1, 3, 4, 2
Oil pressure relief 262-359 KPa
352-448
KPa
Oil pressure switch 29,6 KPa
Valve tip clearance
(cold)
-Inlet
0,2 mm
(0.0078 in)
-Exhaust
0,2 mm
(0.0078 in)
Electrical system 12 volt
Governor Mechanical all speed
Fuel injection Cassette type fuel injection system
