Perkins 103-13 - Rocker Assembly

3
26 Workshop Manual, TPD 1377E, issue 4
100 Series
Rocker assembly
To remove and to fit Operation 3-2
Special requirements
Note: Ensure that the valve stem caps (A1) remain on the valve stems.
Torque Nm (lbf ft) kgf m
102-05, 103-07, 103-10 23 (17) 2,3
103-13, 103-15 23 (17) 2,3
104-19, 104-22 33 (24) 3,3
Bolts (A2) 6 (4) 0,6
102-05
103-07
103-10
103-13
103-15
104-19
104-22
2
1
