Perkins 103-13 - Data and Dimensions; Injection Timing

2
Workshop Manual, TPD 1377E, issue 4 15
100 Series
Data and dimensions
Note: The information in this Workshop Manual is given as a guide for personnel engaged on engine
overhauls. The dimensions which are shown are those which are mainly used in production.
Injection timing
Note: OEM build lists can be found on the relevant service bulletin. If the timing is incorrect refer to "Fuel
injection pump timing" on page 85.
Engine build list Engine type Injection timing
KN30305, KN30306
KN30308, KN30309
102-05 25.5° ± 1°
KN30304, KN30327 102-05 27.5° ± 1°
KL30317, KL30318
KL30319, KL30320
KL30323, KL30324
KL30325, KL30326
103-07 17.0° ± 1°
KD30238, KD30239
KD30240
103-10 23.0° ± 1°
KD30241, KD30242
KD30247, KD30248
103-10 22.5° ± 1°
KD30245, KD30246 103-10 18.5° ± 1°
KH30255, KH30256
KH30273
103-13 22.5° ± 1°
KE30260, KE30261
KE30274
103-15 22.5° ± 1°
KE30262, KE30263 103-15 16.0° ± 1°
KF30265, KF30266
KF30276
104-19 21.5° ± 1°
KR30334, KR30335 104-22 16.0° ± 1°
KR30331, KR30332
KR30333
104-22 20.0° ± 1°
