Workshop Manual, TPD 1377E, issue 4 59
100 Series
Crankshaft retainer setscrews and crankshaft
To remove and to fit Operation 5-3
Special requirements
Check that the oil ways of the bearings match up with the oil ways in the block.
Caution: Before removal and fitting of the crankshaft ensure that the pressure relief valve has been removed.
Notes:
For emissions approved engines. The fuel adjustment screw must not be altered from the original setting.
The maximum No Load Speed must be checked after assembly.
If a new crankshaft is fitted, see Operation 3-13.
Continued
Hex hole setscrews (A1) : Torque Nm (lbf ft) kgf m Hex setscrews (A2) : Torque Nm (lbf ft) kgf m
102-05, 103-07, 103-10 27 (20) 2,7 102-05, 103-07, 103-10 27 (20) 2,7
103-13, 103-15, 104-19, 104-22 27 (20) 2,7 103-13, 103-15, 104-19, 104-22 51 (38) 5,2
